ECM-70 G Gripper Matting
EcoMatPro Gripper matting is our flagship proprietary design for added traction on entry or exit ramps and steep gradients.
Providing uninterrupted access during wet weather, mitigating down time waiting for dry conditions. It can often prove difficult to transport heavy machinery and equipment to the site, especially when there are slippery inclines. EcoMatPro Gripper bog matting overcomes this challenge, ensuring stability and traction on any projects that require temporary roading in these challenging environments.
At EcoMatPro, it is important we provide access or hard standings with minimal environmental impact. Our custom matting design ensures that re-growth can continue and the eco-system is able to return to it’s original state without long lasting damage.
Contact our team today for more information about our ECM-70(G) Gripper matting and how it can be tailored to fit your project.
ECM-70 G | Heavy Duty Gripper Matting
The ECM-70 G is a high-performance modular, eco-friendly ground protection gripper mat designed to support heavy vehicle access and temporary access roads across the civil construction, energy, mining and construction industries. A unique ground protection mat delivering unrivalled grip on steep inclines in muddy wet conditions. The most difficult environment for any industry.
ECM-70 G: The unrivalled matting option for inclines. Delivers a cost-effective durable solution to keep your equipment moving in all weather.
Built using our proprietary Flex Weave bamboo technology, the ECM-70 G offers unmatched strength and exceptional operational efficiency for all equipment. The grip tread can be custom designed to meet your wheel sizes. Challenge us to meet your requirements.
Specifications
|
Description |
ECM-70 G |
ECM Advantage |
|---|---|---|
|
Actual Size |
2.824m x 1.860m x 70mm |
No Comparable product can match the ECM-70 G due to: Specialized Gripper Traction Design, Modularity, Quick Connectors, Industrial Strength, Sustainability. |
|
Useable Area |
5.25m2 (56.5 sqft) |
|
|
Weight |
545 kgs (1,200 lbs) |
|
|
Strength |
1536 psi (10,611 kn/m2) |
|
|
Thickness |
70mm (2.76inches) |
|
|
Mats per 20 ft container |
40 mats |
|
|
Coverage / 20ft container |
157.5m2 (1,695 sqft) |
|
|
Connectors |
4 steel to steel |
|
|
Life |
15 years |
|
|
Repairable on site |
Yes |
|
|
Buoyancy |
Does not Float |
|
|
Fire rating |
Class A ASTM E84 |
How the ECM-70 G Can Boost Your Performance
Operational & Cost Efficiency
The ECM-70 G is engineered to reduce project costs via logistics, reliability and rapid installation.
- Reduce logistics costs: load more mats per truck, increase usable coverage per container vs HDPE
- Rapid Connection: patented 4-way steel to steel quick-lock connectors reduce install time
- Streamlined Deployment: Dedicated lifting points, NO DUNNAGE REQUIRED between mats.
- Repairable On-site: Modular design replace damaged pieces without full mat removal
- High load capacity: 10,611 kN/m² ensures surface stability for heavy equipment
Sustainable Matting
The ECM-70 G is manufactured from Flex Weave Bamboo, our process uses bamboo from certified plantations, our manufacturing process achieves superior strength and resilience.
- Harvested from sustainably sourced bamboo plantations
- Resistant to rot, termites and weathering
- Recyclable at end-of-life, chipped and reused as organic soil mulch
- Carbon-efficient, lower emissions than timber, HDPE matting, or concrete alternatives
- Resistant to fire, does not burn.
With proper maintenance, the ECM-70 G delivers over 15 years of service, making it the ideal solution for companies seeking long-term, low-impact site access with verified ESG performance.
